Image is illustrative
|
Test-disconnect Terminal WTL 6/1/STB, 6mm² 41A 630V, test socket, sliding, beige Code:
1016900000
Price
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.025 kg/pc
|
Volume:
0 m3/pc
|
Wholesale qty:
50pc
|
|
|
|
Test-disconnect terminal WTL 6/1 STB Weidmüller, beige
 |
The versatile and extensive range of products - from 0.05 mm2 to 300 mm2 - means that you have diverse options for your applications at your disposal.
Hardened steel for mechanical strength and high-quality tinned copper for optimum conductivity.
All materials comply with RoHS requirements and have been tested to current environment guidelines.
|
|
| |
Technical data:
|
| Dimensions and weights: |
Width: 7.9 mm
Height: 65 mm
Height of the lowest version: 48.5 mm
Net weight: 23.92 g |
Temperatures:
|
|
Continuous operating temp., min.: |
- 50 °C |
|
Continuous operating temp., max.: |
120 °C |
Product information:
|
|
Descriptive text technical data: |
2.5 mm2 conductor with ferrule with plastic collar, with the collar optimised for diameter only (order No. 1333100000, QTY 500). |
Additional technical data:
|
|
Explosion-tested version: |
No |
|
Open sides: |
right |
|
Type of mounting: |
Snap-on |
|
Version: |
Screw connection, for screwable cross-connection, One end without connector |
CSA ratings data:
|
|
Certificate No. (CSA): |
200039-1057876 |
|
Voltage size C (CSA): |
600 V |
|
Current size C (CSA): |
45 A |
|
Wire cross section max. (CSA): |
8 AWG |
|
Wire cross section min. (CSA): |
20 AWG |
Rated data:
|
|
Rated cross-section: |
6 mm2 |
|
Rated voltage: |
630 V |
|
Rated impulse withstand voltage: |
6 kV |
|
Rated current: |
41 A |
|
Current at maximum wires: |
57 A |
|
Pollution severity: |
3 |
Material data:
|
|
Material: |
Wemid |
|
Colour: |
Dark Beige |
|
UL 94 flammability rating: |
V-0 |
System specifications:
|
|
Product family : |
W-Series |
|
Type of connection: |
Screw connection |
|
Connection direction: |
on side |
|
Number of levels: |
1 |
|
Number of connections: |
2 |
|
No. of clamping points per level: |
2 |
|
Levels cross-connected internally: |
No |
|
Mounting rail: |
TS 35 |
|
End cover plate required: |
Yes |
Classifications:
|
|
ETIM 3.0: |
EC000902 |
|
UNSPSC: |
30-21-18-11 |
|
eClass 5.1: |
27-14-11-26 |
|
eClass 6.2: |
27-14-11-26 |
|
eClass 7.1: |
27-14-11-26 |
|
Approvals:
|
 |
|
|
File description
|
File type
|
Download link
|
|
|
|
|
|
Product data sheet
|
PDF
|
Download link
|
|
|
|
|
