ENCASED TRANSFORMERS FOR T-35 BUS

Type PSS30
Encased protection transformers designed mainly for fitting
into devices using T-35 bus. Elegant casing, featuring spring
bracket significantly facilitates and speeds up attaching.
The transformers are made with Class II insulation and protection grade IP30.
Maximum ambient temperature 40°C, thermal class of insulation B (130°C).
Manufactured in compliance with EN 61558-2-4 and EN 61558-2-6.

Rated power	:10 - 100 VA
Rated voltage PRI	:110 - 500 V 50/60 Hz
Rated voltage SEC	:6 - 250 V
