1914126 « Universal Terminal Block Al/Cu UK150/1PE, 1P (2holes) 35-150mm² 290/320A 1000VAC/ 1500VDC, Hex6 14Nm 25..50mm²/ 35Nm 70..150mm², TS35/ panel mount, MaxPro, yegr Code:
1914124
Manufacturer
:
|
Availability:
In Stock
|
Weight:
0.1694 kg/pc
|
Volume:
0.0002 m3/pc
|
Wholesale qty:
5pc
|
|
|
|
Terminal Block Al/Cu 35-150mm², yegr
 |
|
| Name: |
Terminal Block Al/Cu 35-150mm², yegr |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
yegr |
| Wire mm²: |
35-150 mm² |
| Nominal Insulation Voltage V: |
690 V |
| Screw head size: |
8 mm |
| Nominal Rated Current A: |
Cu 320 A, Al 290 A |
| Number of poles: |
1 |
| Standard: |
SFS 2663 |
| Nominal Tightening Torque Nm: |
14 Nm (25-50mm²)
25 Nm (50-120mm²)
30 Nm (70-150mm²) |
|
|
|
File description
|
File type
|
Download link
|
|
Declaration of Conformity
|
PDF
|
Download link
|
|
|
|
|
|
