Terminal Block Al/Cu 2x2,5-50mm², grey

Name	Terminal Block Al 6-50 mm², Cu 2.5-50 mm², grey
Working temperature (ºC):	max 80ºC
Housing:	polyamide
Fastening:	DIN-rail
Screw head:	hexagon
Colour:	grey
Wire mm²:	Cu 2,5-50 mm² Al 6-50 mm²
Nominal Insulation Voltage V:	690 V
Screw head size:	5 mm
Nominal Rated Current A:	Cu 320 A, Al 290 A
Number of poles:	1
Standard:	EN 61238-1, EN 60947-7-1
Nominal Tightening Torque Nm:	4 Nm (2.5-4mm²), 12 Nm (6-50mm²)
