Hargnemisklemm Block Al/Cu UK50/2PE, 1P (4holes) 2.5-50mm² 290/320A 1000VAC/ 1500VDC, Hex5 4Nm 2.5..4mm²/ 12Nm 6..50mm², TS35, MaxPro, koro Kood:
1914108
Hind
Tootja
:
|
Saadavus:
küsi tarneaega
|
Kaal:
0.0683 kg/tk
|
Maht:
0.0001 m3/tk
|
Hulgipakendi kogus:
6tk
|
|
|
|
Terminal Block Al/Cu 3x2,5-50mm², grey
| |
| Name |
Terminal Block Al/Cu 3x2,5-50mm², yegr |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
yegr |
| Wire mm²: |
Cu 2,5-50 mm² Al 6-50 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
5 mm |
| Nominal Rated Current A: |
Cu 320 A, Al 290 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
4 Nm (2.5-4mm²), 12 Nm (6-50mm²) |
|
|
|
