Hargnemisklemm Al/Cu UK95/1A, 1P (2holes) 16-95mm² 220/245A 1000VAC/ 1500VDC, Hex6 12N 6..25mm²/ 22Nm 35..95mm², TS35/ panel mount, hall Kood:
1914112
Hind
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.1021 kg/tk
|
Maht:
0.0002 m3/tk
|
Hulgipakendi kogus:
8tk
|
|
|
|
Overview
Universal terminal blocks.
Application
Distribution terminal block for mounting on DIN rails or mounting plates, e.g. for installation distributors and meter cabinets according to VDE0603.
Standards
VDE0611-1:2010-03, EN60947-7-1:2009, low-voltage switchgear and controlgear, terminal blocks for copper conductors.
Materials
| Terminal body |
Aluminium, tinned |
| Clamping screws |
Steel, galvanized |
| Insulating housing |
Plastic (PA-66), impact-resistant, flame-retardant |
| Continuous operating temperature |
120°C |
Electrical
| Rated insulation voltage |
690VAC/DC, overvoltage category IV (Uimp=8kV), pollution degree3 |
| Rated insulation voltage |
1000VAC, 1500VDC, overvoltage category II (Uimp=8kV), pollution degree2 |
| Max operating temperature |
70°C |
Mounting / protection
| Mounting |
DIN rail TS35/... according to EN50022, EN60715 (up to UK150) or screw mounting M5 |
| Touch protection |
IP20, finger-safe |
| Safety |
Rounded corners |
Environment
RoHS compliant.
