Pilt on illustreeriv
|
Hargnemisklemm UK95/2N, 1P (4ava) 16-95mm² 220/245A, TS35, paigaldusplaat, MaxPRO, sinine Kood:
1914116
Hind
|
Saadavus:
küsi tarneaega
|
Kaal:
0.2 kg/tk
|
Maht:
0.0003 m3/tk
|
Hulgipakendi kogus:
3tk
|
|
|
|
Terminal Block Al/Cu 2x6-95mm², blue
| Name: |
Terminal Block Al/Cu 2x6-95mm², blue |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
blue |
| Wire mm²: |
16-95 mm² |
| Nominal Insulation Voltage V: |
690 V |
| Screw head size: |
5 mm |
| Nominal Rated Current A: |
Cu 245 A, Al 220 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
12 Nm (6-25 mm2)
22 Nm (35-95 mm2)
|
|
|
|
File description
|
File type
|
Download link
|
|
Declaration of Conformity
|
PDF
|
Download link
|
|
|
|
|
|
