Pilt on illustreeriv
|
Liigpingepiirik BR-12.5-275/4, 4P, T1+T2, Uc 275VAC, impulssvool (10/350μs) Iimp 12.5kA, nimilahendusvool (8/20μs)| Imax 50kA, In 25kA, 4..35mm² 3Nm, TT/TNS, Britec Kood:
B8413
Tootja
:
|
Saadavus:
Laos
|
Kaal:
0.5 kg/tk
|
Maht:
0.0009 m3/tk
|
Hulgipakendi kogus:
36tk
|
|
|
|
Surge Arrester BR-12.5-275/4, 4P, T1+T2, Uc 275VAC, impulse current (10/350μs) Iimp 12.5kA, discharge current (8/20μs)| Imax 50kA ^In 25kA, 4..35mm², TT/TNS, Britec
Features
- T1+T2 - Iimp 12.5 kA per pole.
- Imax: 50 kA per pole.
- Uc: 275 V / 320 V for 230/400V (50/60Hz) power sytem
- Pluggable design.
- Pole number: 1P, 2P, 3P, 4P, 1+NPE, 3+NPE.
- Protection class: Combined Type 1 + 2, Class I + II.
- Conform to EN 6164311 and IEC61643-11.
- No follow current
- Status indicators, green: OK, red: replace.
- The use of high-performance varistor permits a rapid response time and a low protection level.
|
|
|
|
|
